SUMMER ROOM INSTALLERS IN THE SOUTH LAKES

Create the perfect summer room in your home with orangeries from Elegant Products in Barrow-in-Furness. Contact us today for more information from our team about our range of beautiful orangeries and get a free quote on your installation.
Contact

CAPELLA

The Capella is a unique modular system that is a simple yet effective add-on to a standard conservatory. The options available include a high fronted feature aluminium gutter that conceals the end of the glazing bar, and an internal full-height plasterboarded soffit ideal for downlighters or speakers. An appealing orangery solution.

  • READ MORE

    Capella design features

    External gutter options:

    • Standard PVC-U gutter
    • High fronted integral aluminium gutter (that hides the ends of the roof glazing bars)
    • Summer aluminium decorative fascia (as used on the Global Summer orangery)

    Internal soffit options:

    • Shelf-style orangery soffit, using internal brackets (depth of 158mm or 316mm)
    • Fully plastered soffit, using easy to fit angle brackets (depth of 300mm or 600mm, 25˚ pitch as standard). Privacy film (optional) can be professionally fitted to the area of the glass roof that would not allow the homeowner to see the internal workings of the fully-plastered soffit when viewed from an upstairs window above, allowing for a high standard of finish.

    Capella benefits

    • A lower cost orangery solution
    • Usual Building Regulations exceptions apply
    • Easy to fit - adds only 2-3 hours to an installation
    • Available to retro-fit existing builds

GLOBAL SUMMER

Global Summer is a stunning design enhancement of Aperture’s market-leading and proven Global conservatory roof to provide a cost-effective orangery solution. Global Summer delivers the distinguished look of a traditional orangery with external design features precisely engineered to provide a high quality aesthetic appearance.

  • READ MORE

    Global Summer uses high-quality aluminium decorative gutter fascias and internal pelmet pods that cleverly hook onto the eaves beam to create a soffit feature detail. These unique pelmet pods provide a rigid former for easy plastering to create an internal soffit and downlighters or speakers can also be incorporated to create the perfect interior. Optional decorative pilasters are eye-catching, include self-draining flutes and are a beautiful addition to any raised line Global Summer installation.

RIO

The Rio is installed using Aperture's “true” structural orangery system. This is the popular flat-roof orangery design, with the lantern roof visibly “sat” on top. Assembled in exactly the same way as the Integra or the Venetian orangeries, using the single beam framework, the Rio will always be a popular choice. Rio design features include:

  • READ MORE

    • Fully insulated warm roof construction (125mm insulation), available sloping or flat
    • 604mm (D) x 510/550mm (H) internal plasterboard soffit
    • 652mm wide flat roof edge
    • Waterproof EPDM rubber membrane
    • Aluminium/PVC decorative fascia
    • Structural and heat loss calculations available
    • Full technical drawings supplied
    • Roof accessible for maintenance
    • Supplied as a project-specific, easy to fit kit, involving no cutting or drilling of aluminium sections

INTEGRA

The Integra features the structural orangery system. With a “warm roof” system using high strength aluminium, the roof is supported on the cavity walls and lintels. A complete “nut and bolt” assembly with a wide aluminium sectional gutter replaces traditional flat roof membranes. A 210mm version of this system is also available for the more budget conscious customer (Integra 210). Integra features are:

  • READ MORE

    • Fully insulated warm roof construction (125mm insulation) to perimeter gutter
    • 543mm wide integrated aluminium powder coated gutter
    • Fully sealed gutter outlets, full range of decorative aluminium hoppers and downpipes
    • 752mm (D) x 510/560mm (H) substantial internal plasterboard soffit
    • Structural aluminium framework - no timber
    • Full one stop solution for brick perimeter orangery roofs
    • No problem walking on gutters for maintenance
    • Easy to fit kit, no cutting or drilling of aluminium sections

    The Integra 210 utilises our roof system components to produce a compact variation of the Integra parapet orangery style. With a “warm roof” system using high strength aluminium, the roof is supported on the cavity walls and lintels. A complete “nut and bolt” assembly with a wide aluminium sectional gutter replaces traditional flat roof membranes. Integra 210 features are:


    • Uses existing 210mm aluminium gutter
    • 50mm insulation
    • Sealed gutter outlet
    • 425/575 (D) x 400 (H) internal plasterboard soffit
    • Structural aluminium framework - no timber
    • Stable mate of the full Integra roof
    • Full one stop solution for brick perimeter orangery roofs
    • Easy to fit kit, no cutting or drilling of aluminium sections

MODENA

The Modena utilises the Aperture structural orangery system, adapted to include a stunning modern frontage. Designed to either fit between parapet walls or on structural posts, it has the capability to incorporate bi-folding doors up to 6300mm wide (subject to size and loading limitations).

  • READ MORE

    As with all the orangery styles available with Aperture's structural orangery system, the Modena meets all the latest Building Standards. A contemporary design with a unique double-soffit, the Modena is particularly suitable for townhouses and urban-styled architecture. The additional external over-hanging soffit can be fitted with downlighters or speakers, for added appeal. Modena design features include:


    • Same structural principals as the Venetian orangery, plus an additional cantilevered perimeter beam to create an overlapping external soffit
    • Modern-styled external design frieze
    • 1200mm wide integrated aluminium gutter
    • Fully insulated warm roof construction (125mm insulation)
    • Fully sealed gutter outlets, range of decorative aluminium hoppers and downpipes
    • 604mm (D) x 510/550mm (H) internal plasterboard soffit
    • No problem walking on gutters for maintenance
    • Structural and Heat Loss Calculations available
    • Full technical drawings supplied
    • Ideal for townhouses
    • Supplied as a project-specific, easy to fit kit, involving no cutting or drilling of aluminium sections

VENETIAN

The Venetian is installed using Aperture's structural orangery system. Using the same “warm roof” specifications, it features an external aluminium powder coated high frieze, which integrates with the wide gutter and feature hoppers. The result is a truly impressive orangery, for those who are looking for a stylish home extension with a real "wow" factor. Venetian design features include:

  • READ MORE

    • Aluminium roof supported on structural aluminium legs (optional)
    • 490/540mm powder coated aluminium frieze with welded corners
    • Fully insulated warm roof construction (125mm insulation)
    • 543mm integrated aluminium powder coated gutter
    • Fully sealed gutter outlets, range of decorative aluminium hoppers and downpipes
    • 604mm (D) x 510/550mm (H) internal plasterboard soffit
    • No problem walking on gutters for maintenance
    • Structural and heat loss calculations available
    • Full technical drawings supplied
    • Supplied as a project-specific, easy to fit kit, involving no cutting or drilling of aluminium sections
For modern living, discuss your sensational summer room on
